Description
FULL BODY
TRAINING AT HOME
Since 2003, Inspire Fitness has expertly designed and skillfully engineered state-of-the-art equipment. The Centr app comes loaded with workouts for your functional trainer. Train with Chris Hemsworth’s personal trainer, Luke Zocchi, and enjoy the endless creativity Inspire Fitness Functional Trainers offer for your workout routine.
3 MONTHS
DIGITAL TRAINING
To further support your health and wellness journey, Inspire Fitness is now offering Centr digital fitness training and wellness tools to help you reach your goals. Centr brings Chris Hemsworth's team of experts directly to you. Use your Inspire Fitness equipment with exclusive digital workouts and enjoy nutrition advice, recipes, and hundreds of meditations.
360 WELLNESS
Meet our experts that help you meet your goals
TRAIN
Unlock a variety of workouts for your Functional Trainer
EAT
Nutritious recipes to stay on track with your goals
LIVE
Get moving, stay centered
TECHNICAL SPECIFICATIONS
FEATURES:
- Dual adjustable swivel pulley
- 30 vertical pulley positions
- Chin / Pull Up Bar with knurled surface for maximum grip
- Standard rear, woven weight stack shroud
- Standard accessories include: Two (2) Dual Ring Rubber-Grip D-Handles, Black EZ Curl Bar with double swivel attachment points, Black Straight Bar with double swivel attachment points, Triceps Rope, Tablet/Phone Shelf, Built-in Accessory storage
- Dual weight stacks
DESIGN
- Heavy duty steel frame, matte black powder coated
- Pull Up Bar Max User Weight 300 lbs
- Paddle design pulley adjustment lever
- 1/8 inch steel cable
- 3.5 and 4.5 inch glass filled nylon pulleys with sealed ball bearings
- 3/8 inch x 5 inch steel, zinc plated and magnetized selector pin
- Assembled Product Dimensions: 53.9″ W x 82.5″ H x 40.5″ L
- Assembled Product Weight: 536 lbs
- 2 x 160 lbs Weight Stacks
- 2:1 Weight Resistance Ratio per pulley
- Country of Origin : Imported
- Style : FTE 2.0
- DSG Pro Tips
- Brand : Inspire Fitness
Product Information
Color
Matte Black, Chrome
Frame
Heavy-duty round & rectangular steel
Finish
Electrostatic Powder Coat
Bearings
Precision Steel Ball System
Weight Stacks
2 x 165 lbs (2:1 ratio for 82.5 lbs per pulley) {85 lbs max with 5 lbs Add-On Weights}
Weight Multiplier
Doubles weight for heavy lifters, while using the smith bar
Built-In Storage
Accessory Rack, Tablet Mount for mobile devices, Bench mount for FLB2 Folding Adjustable Bench
Included Accessories
Tricep Ropes, 2 x 2-Ring Rubber D Handles, Dual Hook Curl Bar, Ankle Strap, Chin/Dip Belt, 2 x 5 lbs Add-On Weights
Resistance Ratio
2:1
Muscle Groups
All
Warranty
Residential: Limited Lifetime on frame & all parts
DIMS (W X L X H)
59 in x 46 in x 84 in (150 cm x 117 cm x 213 cm)
With Included Bench
With Bench: 59 in x 89 in x 84 in (150 cm x 226 cm x 213 cm)
Weight
631 lbs (286 kgs)
DOCUMENTS
COMPARE FUNCTIONAL TRAINERS |  FTX Functional |  FT1 Functional |  SF3 Smith |  FT2 Functional |  SCS Smith |
Model Number | FTX | FT1 | SF3 | FT2 | SCS |
Price | $2,299 | $2,999 | $4,499 | $4,999 | $4,889 |
Adjustable Sliding Pulleys | 2 | 2 | 2 | 2 | 2 |
Upper Pulleys | - | - | - | 2 | 2 |
Lower Pulleys | - | - | - | 4 | 2 |
Smith Bar | - | - | - | - | Yes |
Selectorized Smith Bar | - | - | Yes | Yes | - |
Pull Up Station | Yes | Yes | Yes | Yes | Yes |
User Capacity | 2 | 2 | 2 | 2 | 3 |
Resistance Ratio | 2:1 | 2:1 | 2:1 | 2:1 | 2:1 |
Weight Multiplier | - | - | Doubles weight on smith bar for 350 lbs (159 kgs) | Doubles weight on smith bar for 350 lbs (159 kgs) | - |
Weight Stacks | 2 x 165 lbs (75 kgs) (2:1 ratio for 82.5 lbs per pulley) | 2 x 165 lbs (75 kgs) (2:1 ratio for 82.5 lbs per pulley) | 2 x 165 lbs (75 kgs) (2:1 ratio for 82.5 lbs per pulley) | 2 x 165 lbs (75 kgs) (2:1 ratio for 82.5 lbs per pulley) | 2 x 160 lbs (73 kgs) (2:1 ratio for 80 lbs per pulley) |
Included Accessories |
|
|
|
|
|
Optional Add-Ons |
|
|
|
|
|
Warranty | Residential: Limited Lifetime on frame and all parts | Residential: Limited Lifetime on frame and all parts | Residential: Limited Lifetime on frame and all parts | Residential: Limited Lifetime on frame and all parts Light Commercial: Limited 10y frame and all parts | Residential: Limited Lifetime on frame and all parts Light Commercial: Limited 10y frame and all parts |
Inspire Fitness SF3 Assembly Video
How to Use the SF3 Smith Functional Trainer
How to Replace the Cables on Your SF3
REVIEWS
SF3 SMITH FUNCTIONAL TRAINER
How long does the unit take to fully assemble?
Times on assembly will vary. If you are a beginner first time build, assembly can take anywhere from 4-6 hours. Expert level builders can complete it in as little as 1 hour.
How many boxes will my unit come in?
The unit comes with 1 box (86.6” x 43.3” x 12.4”) on a pallet (86.6” x 43.3” x 18”) when shipped. Inside the main box, the unit will have the components of the SF3, 6 weight boxes, and 1 FLB2 Folding Adjustable Bench. Please also reference the User Manual for a parts breakdown.
Where can I locate my serial number?
The serial number will be located on the user left base in front of the weight stacks on a white sticker.
What lubricant do you recommend for the unit and what needs to be lubricated?
We recommend using Teflon Based lubricant on all chroming every 3 to 6 months. This includes the Guide Rods your weights utilize, as well as the front shafts on the unit. Please do not use WD-40 or other products besides the recommended Teflon Based Lubricant.
How do I properly install the weight plates for the units?
Please install the plates with the smooth surface side up. The small platforms/feet should be facing downwards. Please also make sure the weight stack number indent is facing towards the inside of the machine.
How much space do I need for the unit?
We recommend a space with a level surface and a clear or usable space of approximately 89 inches in width and 52 inches in depth. You’ll also need a ceiling taller than 96 inches for workable space, but the assembled unit stands at 84 inches tall once complete.
What are the dimensions of the SF3?
The SF3 is 46 inches long, 59 inches wide and 84 inches tall.
How tall is the unit without the pull up bar?
Unfortunately, the pull up bar cannot be removed.
Can I remove the pull up bar without affecting the structure of the unit?
Unfortunately, the pull up bar cannot be removed.
Can I install the unit without the top cross bar?
Unfortunately, the pull up bar cannot be removed.
How much space is on the inside of the unit?
The space inside the unit is 45 inches long and 47 inches wide.
Can the bar be installed upside down?
The bar can only be installed as shown in the User Manual.
Can I upgrade the weight stacks of the unit?
Unfortunately, the weight stacks cannot be upgraded.
How much does one of the main frame stations weigh?
One of the main frames weighs 65 pounds.
How much does the entire unit weigh?
The SF3 complete unit weighs 631 pounds, or 286 kgs.
Can I place my unit outside?
Unfortunately, the unit is not meant to be in an outdoor setting.
How much does the red Smith Bar weigh?
The Smith Bar, without weight pinned on the weight stacks and the bar is not attached to the carriages weights 17 lbs. The Smith Bar and carriages, without any weight plates pinned weighs 37 lbs.
Are the sliders interchangeable?
Unfortunately, the sliders are not interchangeable.
What does the limited lifetime warranty cover?
The limited lifetime warranty of the SF3 covers the main frame, welds, upholstery, hardware, pulleys and cables. For more details, see the User Manual.
How heavy is each weight plate?
Each weight plate is 10 pounds.
How much weight am I lifting per weight stack?
The SF3 has a resistance ratio of 2:1 per pulley, which means the maximum weight you can lift per pulley is 82.5 lbs per pulley.
How much space do I require on the back of the unit?
We recommend at least 6 inches from the wall. However, the unit can be pushed all the way back against a wall if necessary.
How much space do I require on the front of the unit?
We recommend at least a foot of space in front of the unit, but this really depends on how much exercise space you require to conduct your workouts.
How much space do I require on the sides of the unit?
We recommend at least a foot of space on each side. However, if space is tight, we recommend 6 inches. It really depends on the required space for you to properly conduct your workouts.
How can I order parts if I have damages?
You can reach out to our customer service team through our Part Request form here.
Do you have an assembly video of the unit?
Coming soon.
How much does the cable extend from the carriage? (How long/weight stem max out)
The cable can extend up to 98 inches before the top plate hits the top of the machine.
What is the Highest/Lowest Position the Carriage/Swivel pulley assembly reaches?
The Highest position will be 68 inches. The lowest position would be 11 inches.
What is the highest/Lowest set position/usage for red Smith Bar?
The Highest position will be 73.5 inches. The lowest position would be 15 inches.
What is the length of the pull up bar from end to end?
The length is 38 inches.
What is the length of the pull up bar from the interior, short end?
The length is 11 inches.
Am I able to hang another bench on the bench rack (not Inspire)?
If the bench you’re hanging has a handle or hanging mechanism that fits the width of our bench mount, then yes you can.
How do you use the Weight Multiplier feature on the SF3 Smith Bar?
Please reference our User Manual. Video coming soon.
I had a delivery issue with my product, what do I do?
First, contact the delivery company to report any damage or missing pieces. Then, reach out our Customer Service team via web chat at inspirefitness.com, by email at Service@inspirefitness.com, or by phone at 877-738-1729.
How do I register my warranty?
Please visit our online Warranty Registration form.
How long is my subscription valid for?
When purchased through Costco.com, the SF3 comes with a 12-month Premium subscription to the Inspire Fitness app.
How do I renew my subscription after the 12 month promotion ends?
When creating your Inspire Fitness account, you may add a payment method and set up automatic renewal at that time. Otherwise, you may log into your account at app.inspirefitness.com at any time, add a payment method, and opt in for auto-renewal once your promo period is over. The everyday subscription price is $9.99 per month.
What are the resistance ratios of each pull point?
Each pull point is 2:1 ratio.
Are there any accessories you can connect with the unit besides the ones it comes with?
You can add the Dual Hook Straight Bar, Ab Bar, Double D Low Row Handle, Steel 18” Revolving Straight Bar, Sport Handle, or Aluminum EZ Curl Bar.
Can you use the unit without the red Smith Bar?
No, the unit cannot be properly set up without the red bar. If you’re not interested in the Smith Bar, we suggest the FT1 or FTX Functional Trainers.
SF3 Assembly Video
How to Use the Inspire Fitness SF3 Smith Functional Trainer
